- Code000843
- Manufacturer SEA-LAND
Product description
The operation of the waterworks is controlled by a pressure switch, which, when the pressure in the storage tank drops, switches on the pump and replenishes the pressure vessel. The water pressure is thus maintained in the range between the switch-on and switch-off pressure.
The pumps used are of modern design, with a mechanical seal that prevents water dripping. They are driven by electric motors at 230V or 3 x 400V/50Hz. Single-phase motors have built-in overload protection, three-phase motors must be secured with appropriate motor protection.
SEA LAND automatic water pumps are designed to supply family houses, cottages and other smaller buildings with drinking or utility water without mechanical impurities at a temperature of up to 30 oC. The water pump operates automatically and maintains constant pressure in the water supply system. A well, borehole or storage tank can serve as a water source.
Waterworks can also handle watering the garden or filling the swimming pool.
Parameters
| Flow rate Qmax [l/min] | 40 l/min |
| Displacement Hmax [m] | 30 m |
| Warranty period [months] | 24 months |
| Cable length [m] | 2 m |
| Rated motor power [W] | 440 W |
| Max. Temperature [°C] | 30 °C |
| Pump design | superficial |
| Rated voltage | 230 V |
| Drive type | Electric motor |
| Instructions in Czech | Yes |
| Volume [l] | 24 |
